Hydraulic cylinder is one of the indispensable parts of the hydraulic transmission system, widely used in a variety of machinery, automation equipment, hydraulic cylinder model parameters for the normal operation and performance of mechanical equipment plays a very important role. Often there will be purchasing or do not know the technology of the traders, provide other enterprises cylinder model for us to quote, this is actually a misunderstanding, because the cylinder industry has no national standard, each factory has its own product model, and the model of the numerical value, on behalf of the meaning of the different, there is no comparability. Therefore, to be able to correctly provide the following parameters is the critical first step in customizing and purchasing cylinders.

First, the hydraulic cylinder model parameters:

1. inside diameter (Piston Diameter): that is, the piston diameter inside the hydraulic cylinder, the length is usually millimeter (mm) level.

2. Stroke (Stroke): refers to the piston inside the cylinder to move the distance, the length is usually millimeters (mm) level. 3.

3. working pressure (Working Pressure): refers to the maximum pressure that the hydraulic cylinder can withstand, usually in MPa (MPa) or Bar as a unit. 4. working temperature (Working Pressure): refers to the maximum pressure that the hydraulic cylinder can withstand, usually in MPa (MPa) or Bar as a unit.

4. working temperature (Working Temperature): refers to the temperature range of the normal operation of the hydraulic cylinder, usually in degrees Celsius (℃) as a unit.

5. cylinder body material (Body Material): refers to the main components of the hydraulic cylinder material, usually cast iron, steel, etc..

6. cylinder cylinder size (Tube Sizing): refers to the hydraulic cylinder cylinder outside diameter size, for the millimeter (mm) level.

Second, the application of hydraulic cylinders:

     Hydraulic cylinders are widely used in a variety of mechanical equipment, such as excavators, loaders, shovels, cranes and other heavy machinery and equipment. Its application field is not only limited to the field of heavy industry, but also can be used in light mechanical equipment or other automatic control field, in order to realize the mechanical parts of the movement, lifting, clamping and other work.

Third, how to choose the appropriate hydraulic cylinder model parameters:

1. according to the working pressure of the equipment to choose the appropriate hydraulic cylinder model parameters. 2. according to the required thrust and thrust of the equipment.

2. according to the equipment required thrust and lifting height to determine the stroke length of the hydraulic cylinder and the value of the inner diameter. 3. according to the environmental temperature of the equipment.

3. according to the equipment in the environment temperature selection of the appropriate operating temperature range. 4. according to the equipment to load the weight.

4. according to the equipment need to load weight and the special requirements of the working environment to choose the appropriate cylinder material.

   In the selection of hydraulic cylinder model parameters, but also need to consider its durability, strength and reliability requirements.

   In short, the hydraulic cylinder model parameters for the normal operation and performance of mechanical equipment plays a very important role. In the selection of hydraulic cylinder type parameters should be selected according to the specific needs of the equipment to improve the productivity and performance of the equipment.
